Detailed Product Description
Type: Drop Arm Barrier Service:: OEM&ODM
Longevity:: Heavy Duty Frameworks:: 304 Or 316 Stainless Steel
Material: 304 Stainless Steel Flap Barrier: Net Weight: 90kg
Intelligent Parking Control System Swing Barrier Gate Access Control Turnstile
Intelligent parking control system drop arm barrier
Features and functions:
1. Fault detection and alarm functions, easy to use and maintenance.
2. The running status can be programmed and controlled with the built-in keyboard on the main board.
3. Mechanical anti-pinch function. If the gate meets resistance in the reset process, motors will stop working automatically within the prescribed time and reset again after the default delay (till fully reset).
4. Anti-breakthrough function. The arms are locked automatically until opening signal received.
5. Synchronization functions (for dual gate equipments).
6. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically.
7. Passage can be set as normally open or normally closed.
8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
9. Direction can be set as single-direction or bi-direction.
10. LED direction indicator.
11. Arms auto drop when power off and auto rise when power on, complying with fire safety requirements.
12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.
13. Counter function (optional).
14. Support infrared photocell for anti-pinch and reset function (optional).
Model Item RS 1009
Voltage AC 220V/110V± 10%
Control circuit: DC24V
Power consumption 40W
Working temperature -20° C~60° C
Working humidity 0~95%RH
Self-inspection of fault and alarm indication function, convenient for maintenance and usage.
The rod is automatic fall when power is off and self-inspection when the electricity is on and automatic recovery to the locked status.
Various kinds of working modes which can be optional, such as bi-directional card reader; Read card at one side while forbidden passing on the opposite side; Read card at one side while allow passing on other side; Passing through infrared sensor in single and bi-directional way, the rod will be lifted and fall the gate will be closed when detected the person is passed. And the working mode of gate is setting through main menu.
The infrared sensor detected the pedestrian who read valid card has passed, it will be lifted the rod and closed the gate automatically or delay lift and fall after the pedestrian has passed, able to delayed 1~60 seconds which can be set through the main menu.
Able to reset automatically. If the pedestrian read the card but did not pass in the specified time, the system will be cancelled the passing rights of this time. The limited time of passing can be set by administrator.
If pedestrian forgot or read invalid CAD, forbidden to pass and alarm till the pedestrian quit the channel of turnstile. Allow passing after re-read valid card.
In order to meet clients' special requirement and fire safety requirement, the port of communicate interface 485 can be controlled the lifting and falling of rod at long distance.
Prevent rush function, the rod of the gate will be locked when it hasn't got the open signal.
Double anti-pinch function infrared sensor and machine.
Unified and Standard external electric interface can be connected with various kinds of read and write device, convenient for system integration, and able to accomplished remote control through computer management.
Able to statistics the numbers of pedestrian on passing direction, and show it to the administrator as the manner of LED (optional)
Memory card reader and non-memory card reader, user can be set according to their own needs.
Able to limit the numbers of the inner worker through setting the software, to meet some special requirements in special place.
Operating smoothly, low noise.
Apply to control flow of single or bi-directional entrance and exit channel.
The entrance and exit channel of station, pier and tourist attractions.
The ticket checking channel of exhibition, swimming stadium.
Access control of entrance and exit channel of office buildings, hotels, enterprises.
Able to control special channel.
1. One year warranty; life-time professional technical supports
2. Support customized turnstile gates or OEM
3. One-stop access control/ security solution provider, can help you save time and costs
4. Good quality with competitive price
5. Fast delivery, well-protective package and safe shipping way
1. Guarantee & after sale service?
Strictly quality testing before shipment and 1 year quality guarantee.
Equipped with well-trained professional R&D engineers and sales to provide you timely help.
2. Lead time?
For standard item
10-50 sets:5 working days
0-100 sets:7-10 working days
200-500 sets:10-15 working days
For customized item or package , 3-10 working days longer
3. Payment terms?
TT , Western Union, Paypal, L/C, Cash are available.
For sample, usually delivery by air or by express, takes about 3-5 days.
For quantity purchase with big volume and heavy duty, normally by sea, you can choose your own forwarder. Takes about 10-60 days depends on different countries.
Standard carton box, better pack it by wooden case to protect the products
6. OEM service available?
Yes, we can offer OEM services as follows:
1) Customize design according to your requirements is acceptable.
2) Print your logo on goods, and customize retail box packing and other things. Large amount logo print is for free
