Specification
Display 61 mm x 34 mm supper large
LCD display.
15 mm ( 0.6′′ ) digit size.
Memory Maximum & Minimum value.
Sampling time Approx. 1 second.
Operating
temperature
0 to 50 °C ( 32 to 122 ).
Measurement Velocity, Acceleration RMS
value, Peak value, Data hold,
Max. & Min. value.
Operating
humidity
Less than 80% RH.
Range Velocity :
200 mm/s : 0.5 to 199.9 mm/s
Acceleration :
200 m/s2 : 0.5 to 199.9 m/s2
Power supply Alkaline or heavy duty type,
DC 9V battery, 006P,
MN1604 (PP3) or equivalent.
Power
consumption
Approx. DC 6 mA.
Frequency
range
10 Hz to 1 KHz
* Sensitivity relativive during
the the frequency range meet
ISO 2954
Weight Meter 274 g/0.60 LB
Probe with
magnetic base
38 g/0.08 LB
Accuracy ± ( 5 % + 2 d ) reading
@ 80 Hz, 160 Hz.
@ 23 ± 5 °C
Dimension Meter : 185 x 78 x 38 mm
( 7.3 x 3.1 x 1.5 inch ).
Vibration sensor probe:
Round 16 mm Dia. x 29 mm.
Calibration
point
Velocity : 50 mm/s (160 Hz)
Acceleration :
50 m/s2(160 Hz)
