Mitutoyo 514-105 Vernier Height Gauge, 0-18" Range
Brand New
Condition
Calipers
Type
Analog
Display
450mm
Caliper Max Length
0.01mm
Caliper Resolution
0.002mm
Accuracy
in, mm
Measuring Units
Store address
Rivers State • Port-Harcourt
No 11 Trans Amadi Industrial layout Bedkana yard opposite Zenith Bank plc
09:00-18:00
The Mitutoyo 514-105 vernier height gauge has a measurement range of 0” - 18"/0 - 450 mm, and is graduated in both inches and metric to 0.001”/0.02 mm, with + or – 0.002”/0.05 mm of accuracy.
The scriber, used to mark a position on a workpiece, is 32 mm x 80 mm (H x W), carbide-tipped for hardness and to help prolong life, and is held to the gauge by a screw clamp for secure fastening. The grip-base helps hold the unit in position by hand. An adjustable beam with a ring-type lock nut supports repositioning of the zero reference point for manual change of the base position. The slider and beam are made of hardened stainless steel, with a glare-free satin chrome finish that helps resist rust. The height gauge weighs 7.5 lbs/3.4 kg.
A vernier scale provides precise measurement through a second sliding scale that indicates where measurement lies between marks on the main scale. A calibrated screw mechanism supports fine, uniform slider adjustments.
