The CVR CV-28 is a high-performance dual 18-inch subwoofer designed for large-scale audio applications such as live sound reinforcement, touring, and fixed installations. It is available in both passive (CV-28) and active (CV-28P) configurations.
-
CVR CV-28 Subwoofer Specifications
Model: CV-28 (Passive) / CV-28P (Active)
Type: Dual-driver sub-bass system
Frequency Response: 30Hz – 500Hz ±3dB
Power Handling:
2000W RMS
8000W Peak
Sensitivity: 103dB (1W @ 1m)
Maximum SPL: 135dB (Peak @ 1m)
Drivers: 2 × 18" (460mm) woofer with 100mm (4-inch) voice coil
Nominal Impedance: 4 ohms
Enclosure: Birch plywood with textured high-density polyurethane coating
Connectors: 2 × NL4MP Speakon
Dimensions (W × H × D): 1130 × 580 × 907 mm
Net Weight: 100 kg (CV-28) / 103 kg (CV-28P)
Gross Weight: 107 kg (CV-28)
