Maximum Power (Pmax): 530 Watts
Module Efficiency: ~20.5% – 21%
Voltage at Max Power (Vmp): ~40.5 V
Current at Max Power (Imp): ~13.0 A
Open Circuit Voltage (Voc): ~49.2 V
Short Circuit Current (Isc): ~13.7 A
Power Tolerance: 0 ~ +3%
Physical Specifications
Dimensions: ~2274 × 1134 × 35 mm
Weight: ~28.5 – 29 kg
Cells: 144 half-cut mono cells (72 full-cell equivalent)
Glass: 3.2 mm tempered, anti-reflective
