Concrete Pump

+1

Concrete Pumps

Type

Other

Make

DHBX60-11-76

Model

Brand New

Condition

2025

Year of Manufacture

2800kg

Operating Weight

32MPa

Pressure

60rpm

Pump Cycles

350L

Hopper Capacity

76kW

Engine Power

70L

Fuel Tank Capacity

Yes

Exchange Possible

DHBX50 Diesel Concrete Pump Model: DHBX50-11-76 Pumping capacity: 50 m3/hour Engine: Weichai diesel engine Engine power: 76 kW Maximum delivery pressure: 11 MPa Horizontal pumping distance: 300 m Vertical pumping distance: 110 m Hopper capacity: 350 L Fuel tank: 70 L Delivery pipe diameter: 125 mm Standard delivery pipe: 100 m Machine weight: 2,800 kg Machine size: 4500 × 1500 × 1750 mm Concrete slump range: 120–200 mm Maximum aggregate size: 40 mm (pebbles) / 30 mm (crushed stone) S-valve system. It comes with delivery pipes, elbows, rubber hoses, clamps, sealing rings, remote control, cleaning balls, tools, user manual and service documents
