600w Jinko Bifacial Panel

+1

JinkoSolar

Brand

Solar Panels

Type

Hybrid Inverter

Inverter Type

Brand New

Condition

Monocrystalline

Panel Type

144

Number of Cells

600watts

Solar Panel Power

48V

Panel Rated Voltage

49%

Efficiency

Store address

Lagos State • Ojo

Shop 2006 f. Line alaba international market

From alaba international market, enter inside f. Line ask of shop 2006 upstairs

Closed

• Mon - Sun, 06:30-06:40

Key specifications (stc: 1000 w/m2, 25°c, am 1.5) — jkm600n-66hl4m-bdv (bifacial) • nominal power (pmax): 600 wp • module efficiency: ~22.21% • voltage at max power (vmpp): 40.16 v • current at max power (impp): 14.94 a • open circuit voltage (voc): 48.28 v • short circuit current (isc): 15.84 a • power tolerance: 0 ~ +3% (or similar) noct (nominal operating cell temperature) values are lower (e.g., pmax around 453 wp under noct conditions). temperature coefficients • pmax: -0.29 %/°c • voc: -0.25 %/°c • isc: +0.045 %/°c • operating temperature range: -40°c to +85°c (or +70°c in some listings) mechanical characteristics • cell type: n-type monocrystalline (topcon) • number of cells: 132 (2 × 66, half-cut) • dimensions: 2382 × 1134 × 30 mm • weight: ~32.4 kg • bifaciality factor (approx.): 80 ± 5% (for rear-side gain)
