Large LCD display for easy reading.
High accuracy and performance for low resistance measurements.
4-wire cables with Kelvin clip connectors, capable of testing extreme low resistance.
Accurate measurement of conductor, electric heating elements and solder point.
High measurement range of 0.01mΩ to 2kΩ at 6 ranges.
HOLD key for data hold.
Backlit LCD for easy reading under dark light.
Connection for external power supply.
Strong anti-magnetic and anti-jamming functions.
Full function protection.
Manual zero display adjust.
Built into compact, durable field service housing with protective cover.
Specifications:
20 mΩ ±(1.5%rdg±3) 0.01 mΩ About 100mA.
200 mΩ ±(0.5%rdg±3) 0.1 mΩ About 50mA.
2 Ω ±(0.5%rdg±3) 1 mΩ About 50mA.
20Ω ±(0.5%rdg±3) 1 0mΩ About 50mA.
200Ω ±(0.5%rdg±3) 1 00mΩ About 50mA.
2kΩ ±(0.5%rdg±3) 1Ω About 50mA.
Sampling
