25.6v, 100ah = 2.56kwh total. 2.3kwh usable @ 90% dod
• battery type: lifepo4 prismatic cells. built-in smart 50a bms
• cycle life: 6000 cycles @ 80% dod. ∼8-10 years lifespan
• charge/discharge: max charge 50a. max discharge 50a. recommended 25a charge / 40a discharge
• dod: 90% usable
• communication: rs485, can. plug & play with felicity, must, axpert, sako, sms, haisic 24v inverters
• design: wall mount powerwall. ip20. led indicators + lcd for soc, voltage, current, temp
• operating temp: -10°c to 55°c. weight ∼28-30kg. size: 400 x 350 x 160mm
• scaling: parallel up to 15 units = 38.4kwh @ 24v
• warranty: 5 years
good for
1 bedroom flat, shop, office with 2.5kva / 3kva 24v inverter.
can run: tv + 2 fans + lights + fridge for 3-4hrs
can run: 1x 1hp ac for 1-1.5hrs only
