Range of product
HDB3w
Product or component type
Miniature circuit-breaker
Device application
Isolation
Control
Poles description
2P
[In] rated current
13 A
Complementary
[Ue] rated operational voltage
415 V AC 50/60 Hz
Breaking capacity
3.0 kA
Dielectric test voltage
2.0 kV 50/60 Hz 1 min
[Uimp] rated impulse withstand voltage
4.0 kV
Magnetic tripping limit
10... 14 x In
Curve code
D
[Ui] rated insulation voltage
250.0 V between phase and ground
500.0 V between phases
Suitability for isolation
Yes
Mounting support
35 mm DIN rail
Protection type
Overload protection
Short-circuit protection
Cable entry
Top
Bottom
Mechanical durability
25000 cycles
Electrical durability
6000 cycles
IP degree of protection
IP20
Overvoltage category
II
Provision for padlocking
Handle padlockable in on and off position
Connections - terminals
