Atures
24v 100ah / 200ah lithium ion battery for energy storage system.
waterproof : ip65 protection level.
floor or power wall mounting.
support connected in parallel mode for expansion (up to 12 pieces).
built-in battery management system(bms).
built-in air switch, double protection.
iron phosphate-lithium battery powerwall ôoö90% dod , more than 6000 cycle times.
long warranty periodôoö5 years.
convenient can&rs485 communication.
model lpbf24200-m
size : 537*537*298
model
lpba48100-ol
lpba48200-ol
capacity
48v 5.12kwh
48v 10.24kwh
voltage
48v
48v
rated voltage
51.2v
51.2v
charge voltage
57.6v
57.6v
discharge voltage range
48-57.6v
48-57.6v
max.charge&discharge current
120a
120a
dod
90%
90%
modeles connection
1-12 in parallel
1-12 in parallel
ingress protection
ip65
ip65
cycle life.
