Capacity (va/w) 2000va/1600w
nominal battery voltage 24vdc
line mode input nominal voltage 220vac
voltage range 170-280vac (narrow range) 90-280vac (wide range)
normal frequency 50hz or 60hz
output volatge 220vac frequency/ waveform following the utility
transfer time 20ms typical back up mode
output voltage 220vac
frequency 50hz or 60hz (auto detection) waveform simulated sine wave
protection discharge,
over-charged, over-loading, overtemperature, short circuit protection
battery charger (powered by ac) charging algorithim 3-step charging
ac charging mode 10a/20a
floating charging voltage 27.50±0.50v
overcharging voltage 30.6v
general physical dimension (d*w*h) 316mm(d)*227mm(w)*92mm(h)
battery features:
200ah battery capacity
12v battery voltage
gel battery
