Parameter | specification |
|- |- |
| **model** | ce-gcl-12200 |
| **cell chemistry** | lithium iron phosphate (\text{lifepo}_4) |
| **total stored energy** | 2.56 kwh (2,560 wh) |
| **nominal voltage** | 12.8v |
| **nominal capacity** | 200 ah |
| **normal output power** | 1,280 w |
| **charge cut-off voltage** | 14.4v – 14.6v |
| **discharge cut-off voltage** | 12.0v |
| **recommended charge/discharge current** | \le 100\text{a} |
| **max charge/discharge current** | 150a – 200a |
| **cycle life** | \ge 3,200 cycles at 25^\circ\text{c} (up to 80% dod) |
| **depth of discharge (dod)** | 80% – 90% |
| **weight** | approx. 17.6 kg – 22 kg |
| **enclosure rating** | ip21 / ip20 (indoor use) |
