Product Name: Liquid-Filled Groundmount Transformer; 3PH, 2500 kVA, HV 33000D , LV 415yn
Rated Power 2500[kVA]
Insulation Liquid: Mineral Oil
High Voltage: 33000[V]
High Voltage tappings (DETC): +2 -2 2.5%
Low Voltage at no Load: 415[V]
Number of phases 3
Vector Group: Dyn11
Ambient temperature max./monthly/annual average: °C 40 / / 20
Max. average temperature rise (Oil/Winding): 60 / 65[C/C]
Location Indoor/Outdoor
Rate Voltage: 33-0,415KV
Frequency: 50[Hz]
Impedance: 6(+-10%)[%]
No Load Losses: 3800(+15%)[W]
Load Losses at 75 °C: 32000(+15%)[W]
Standards: IEC 60076
Total Weight: 4901[kg]
Cooling: ONAN
