Key features:
rated capacity: 300kva
input voltage range: typically ±20% to ±50% (customizable options available)
output voltage: 380v ±1% (or customized per client request)
frequency: 50hz/60hz
control system: advanced microprocessor-based servo system
cooling method: natural air cooling or forced air cooling
products specification
technology servo motor control+toroidal transformer, efficiency >97%
input voltage 175vac-265vac (phase voltage) 304vac-456vac(line voltage)
output voltage single phase: 220vac three phase:380vac
output accuracy (1%~5%)
protection over voltage, overload, high temperature, short circuit(with fuse or circuit breaker)
operating temperature -20~50°c
operating relative humidity 10%rh-102%rh: non condensing
