1.5hp = 1100w
• voltage: dual power - dc 180v - 350v or ac 220v - 240v 50hz
• current: dc 8a | ac 6a
• pump type: 4-inch submersible multi-stage centrifugal
• motor type: permanent magnet brushless dc + ac induction hybrid
• speed: 3000rpm
• insulation: class f | ip68 waterproof
• material: stainless steel 304 body + noryl impellers
• cable: 4x4mm2 x 50m included
controller / inverter box
• input: solar dc 180v-350v + ac 220v auto switch
• priority: solar first. when sun is low, auto switches to ac
• mppt: built-in mppt 98% efficiency
• protection: dry run, overvoltage, overcurrent, overload, lightning, phase loss
• display: lcd shows pv voltage, ac voltage, current, flow, speed, fault code
• enclosure: ip65 weatherproof box
• max solar input: 1800w dc
