DAB Grinder 1800T Manual Pump 415v
DAB Grinder 1800 T Manual Pump.
Cast iron pump body, motor casing, suction cover and adjustment ring impeller. Grinder device in micro cast steel.
Stainless steel shaft, handle, bolts and screws. Silicon/carbide mechanical seal, inspectionable oil chamber.
Pumped liquid: sewage, waste waters, raw loads containing solid particles and/or long fibres, not-aggressive in all cases.
Submersible cast iron pump with triturator suitable for lifting or drainage installations for civil and industrial sewage.
Thanks to the grinding system, the material present in the sewage (organic waste,fabric, rubber, etc.) is reduced into small particles, allowing the liquid to be pumped without any risk of clogging or obstruction of the delivery pipes.
Constructional features of the pump
Cast ironpump body, motor casing and suction cover.
High-resistance cast iron thrust ring pipe impeller.
Triturator device obtained by precision casting of extremely strong and durable materials.
Stainless steel rotor shaft, handle and screws.
Inspectable oil seal chamber.
Silicon carbide mechanical seal.
The supply vent of 2" threaded GAS is radial to facilitate assembly on the lifting devices (DSD 2).
Constructionalfeaturesof the motor
Continuous duty submersible induction motor, in a watertight casing.
Rotor mounted on oversized greased sealed-for-life ball bearings.
Thermal protection in the windings, to be connectedto the control panel.
In order to operate, the pumps must be equipped with a control and protection system, supplied separately and not connected to the electropumps.
Supplied with 10 metres of neoprene rubber power cable 6x(4x1.5)+(2x0.5).
Motor protection: IP68
Insulation class: F
Manufactured according to CEI 2-3 standards.
single-phase 220-240 V/50 Hz
three-phase 400 V/50 Hz
- Operating range:
from 2 to 9 m3/h with head up to 24.5 metres for the
single-phase version and 26.5 metres for the three-phase version.
- Liquid quality requirements:
dirty waste water, untreated sewage containing
solids and/or long fibres, always non aggressive
- Liquid temperature range:
from 0°C to +55°C
from 0°C to +40°C for the Ex version
- Maximum ambient temperature for pump operation with the motor emerging: +40°C
- Maximum immersion depth: 10 metres
- Installation: fixed or portable in a vertical position
