Checking open circuit, short circuit, reverse connection.
Exact locating of the fault.
Checking wiring errors in 5e, 6e, and telephone cab
Measure twisted-pairs length (up to 400m).
Long battery life (up to 50 hours).
Simple and easy use.
Large LCD display.
In most cases the far-end of the cable is located too far to be connected to the loopback port, so it should be terminated with the far-end adapter. Fault finding is performed in Pair&length mode. If there is any short circuit, "SHORT: yz" information will be displayed (yz - the numbers of short-circuited wires). It has to be fixed before any further measurements. In the case of open circuit the device will display the distance (in meters) to the place of fault.
SPECIFICATIONS
Tested cable types:
twsited-pair 5e, 6e; phone cable
Connectors:
RJ-45 sockets
