Specifications
Power6KVA / 4200WVoltage range176 ±5VAC~276 ±5VACFrequency46~54Hz ±0.5Hz, or 56~64Hz ±0.5Hz auto-sensingInput phaseSingle-phasePower factor≥0.98Voltage range220VAC ±1%Output 10min turn to Bypass mode,
> 130% 1s turn to Bypass modeCrest factor3:1 (max)WaveformPure sine waveTransfer time0ms (AC mode - Battery mode)
0ms (AC mode - Bypass mode)Efficiency≥88%AC mode5 cycles turn off the inverter, no transfer to Bypass,
provide alarm.Battery mode5 cycles turn off the inverter, provide an alarm.Bypass modeInput fuse has blown or break action.Battery Model12V sealed lead operationNoise level≤ 55dBTemperature0~40 C; 0 ~ 40 C (storage temperature)Humidity0~95% (non-condensing)Altitude< 1500mWeight Net/Gross89/104kg (standard unit); 34/48kg (long time unit)Dimension (WxDxH)270 x 570 x 720mmPackaging (WxDxH)370 x 670 x 940mm
